MULCHER MZ

A three-rotor, semi-mounted rotary cutter

HIGH DAILY OUTPUT IN COMBINATION WITH LOW COSTS

MULCHER MZ three-rotor, semi-mounted rotary cutters with a working width of 4.5-5.8 metres are very popular machines that combine a high area capacity with low demand for the tractor towing power. The robust frame with hot-dipped galvanized body predetermines the rotary cutter to be maximally used in the most demanding conditions of an agricultural operation.

#

4.5-5.8 m

#

120-200 hp

Key properties

A semi-mounted rotary cutter with a working width of 4.5– 5.8 m designed for quality mulching of crop residue, unwanted tree seedlings and grasses, with a high daily output.

MULCHING

An essential operation in crop residue management.

Mulching vegetation contributes to a balanced growth of above ground matter, processing ungrazed grass (bad quality fodder not grazed by the cattle), it promotes grass offsetting, and also prevents the development of weeds.

In this case, the rotary cutter crushes, shortens and evenly distributes the mulched material, which is then better incorporated into the soil and also decomposes faster. Mulching is also important for mechanical prevention of diseases and elimination of pests, such as the European corn borer.

Weeds and dispersed tree seeds do well in maintained land. To reduce their occurrence, the land needs to be mulched well to prevent seeding and other unwanted spread.

Mulching permanent grassland, pastures and meadows Mulching oilseed rape, cereal and corn stubble field Mulching unwanted tree seedlings, seeding and land maintenance
ROBUSTNESS AND QUALITY OF WORK

Ensures high durability and safety at work.

The MULCHER MZ semi-mounted rotary cutters are highly durable and designed for hard work. Hot-dipped galvanization of the machine provides high resistance to vegetation sap, collision with rocks, or weather conditions.

ROBUSTNESS AND QUALITY OF WORK
TWO PAIRS OF BLADES

Perfect material cutting and disrupting in one pass.

Quality mulching requires a large rotor diameter and high circumferential speed. The MULCHER MZ mounted rotary cutter is equipped with two pairs of shaped knives on the rotor to ensure excellent quality of work. The blades can be used both for mulching grasses and processing crop residue.

TWO PAIRS OF BLADES
SMOOTH SURFACE

Prevents dirt from sticking to the machine.

MULCHER MZ can be equipped with cover plates of the main frames. The plates are smooth and minimize the sticking of plant residue on the machine.

HLADKÝ POVRCH
CENTRAL WALKING AXLE

For better terrain tracing.

When compared with the standard model, MULCHER MZ can be equipped with a walking version of the central axle. The machine is then able to better trace any terrain unevenness and maintain the set working width. You can achieve an even better effect in combination with the tandem version of the side axles.

CENTRAL WALKING AXLE
FRICTION CLUTCH

An effective protection of the gearbox.

The transmission part of the MULCHER MZ semi-mounted rotary cutter is protected against damage (for example, in the case of a collision with a rock, etc.) with a friction clutch that automatically stops all the transmission processes. The cardan shaft connecting the tractor with the gearbox is equipped with a friction clutch.

TŘECÍ SPOJKA
WORKING POSITION WITH LIFTED WINGS

Suitable for mulching field and road edges.

The side wings of the MULCHER MZ rotary cutter can also be lifted, for example, when mulching unwanted tree seedlings along field edges. The wings work on a swinging arm and perfectly trace the unevenness of land to be mulched from −15° to +45°.

WORKING POSITION WITH LIFTED WINGS
HIGH-QUALITY CARDAN SHAFT

By Walterscheid.

When manufacturing BEDNAR rotary cutters, we use high-quality cardan shafts by Walterscheid.

KARDANY VYSOKÉ KVALITY
TRASH-FAN

Machine cleaning equipment.

The main component is the fan that creates a stream of air and the wind straighteners direct air to the risk areas on the machine surface. The equipment prevents dirt and plant matter from sticking on the machine surface. It improves labour safety and reduces time spent with cleaning.

EQUIPMENT FOR MAXIMUM WORK QUALITY

Front counter blades, spreading deflector or armouring.

Counter blades that provide the final cutting of the mulched material are installed in the front part of the mulching area to increase the crushing effect. That easily increases the quality of material mulching.

The spreading deflectors ensure that the rotary cutter works perfectly as they evenly spread the mulched material. They prevent the formation of plant clumps and larger amounts of matter in one place.

The MULCHER MZ semi-mounted rotary cutter is equipped with replaceable armoured plates that protect the machine frame from damage. Moreover, each rotor is protected with its own cover, which enables to work in an extremely low position above the ground.

PŘEDNÍ PROTIOSTŘÍ PROTIŘÁDKOVACÍ CLONA PANCÉŘOVÁNÍ

ARE YOU INTERESTED IN THIS MACHINE? DO YOU HAVE A QUESTION?

Do not hesitate to contact us or find the dealer for your area.

Contact us Find a dealer

Machine description

A concise summary of the main working parts of the semi-mounted rotary cutter.

MULCHER MZ Semi-Mounted Rotary Cutter

Take a look at your future machine.

# # # # # # # #
Drawbar

The rotary cutter is easily aggregated to the bottom or top tractor hitch. It can also be connected using the K80 ball pin.

Blades

Two pairs of bent blades provide an excellent cutting and crushing effect. There are two blade models available – grass and corn.

Axle

The central walking axle provides excellent terrain trafficability, and even better tracing when compared with the standard model.

Rotor covers

They protect the rotor and enable to work in an extremely low position above the ground.

Runners

The side runners maintain the set working height.

Hot-dipped galvanized frames

They provide an outstanding resistance to aggressive vegetable saps or mechanical damage (e.g., collision with a rock).

Trash-Fan for machine cleaning

It prevents dirt and plant matter from sticking on the machine surface and increases labour safety.

OUR INNOVATIVE TECHNOLOGIES

TRASH-FAN CLEANING SYSTEM

The device for continuous machine surface cleaning is mounted centrally on the machine to provide the best possible effect at work, and also compactness during transport.

TRASH-FAN CLEANING SYSTEM

WHAT DO THE FARMERS HAVE TO SAY?

“We decided to purchase the machine after we saw a demonstration in a grain maize stubble field and meadow grass. We tried competitive hammer cutters in the same conditions, but the quality of work did not meet our demands. Therefore, the MULCHER MZ 6000 rotary cutter was the obvious choice; it worked perfectly in the stubble field as well as in the meadows. Another decisive factor was that the rotary cutter with a working width of 6 metres does not need such a towing power as the competitive machines.”

Pavel Joneš,
a machine operator, ZOD Rasošky, Rasošky (district of Náchod, CZ)

Accessories

We know that everyone has different requirements for the optional machine equipment and its expected use. Therefore, you can specify your MULCHER MZ semi-mounted rotary cutter to precisely match your needs.

Blades

Corn blades

We achieved double-crushing hard stalks, such as grain maize, sunflower, or oilseed rape, by combining the paddle-shaped blades mounted in the lower plane and straight blades mounted in the upper plane. The stalks are cut at two levels at the same time.

Corn bladesCorn blades

Grass blades

The paddle-shaped bent blades, cross-mounted on one plane, are suitable for mulching permanent grassland. The paddle-shaped knives create a suction effect, which lifts the grass run over by the tractor wheels and helps mulching the grass.

Grass bladesGrass blades

Other

TRASH – FAN

The main component is the fan that creates a stream of air and the wind straighteners direct air to the risk areas on the machine surface. The equipment prevents dirt and plant matter from sticking on the machine surface.

TRASH-FAN CLEANING SYSTEMTRASH-FAN CLEANING SYSTEM

CONFIGURE YOUR OWN
MULCHER MZ Semi-Mounted Rotary Cutter

You are one step closer to your new machine.
You can try all the equipment in our configurator,
or read about it in the brochure.

Configure Brochure

AGRONOMICAL GUIDE

CROP RESIDUE MANAGEMENT
Processing crop residue after harvest is important for several reasons. Crop residue is a source of organic matter therefore it is not desirable to simply leave it in the field without attention. Crop residue may be unevenly spread which aggravates soil cultivation and the clumps facilitate the spread of diseases and breeding of pests.

How to work with crop residue?

Technical data

The table can be navigated by scrolling sideways.
MULCHER MZMZ 4500MZ 4500MZ 6000
Working widthm4,54,55,8
Transport widthm2,32,32,4
Transport lengthm5,65,65,9
Transport heightm2,22,22,8
Power take-off speedRPM5401 0001 000
Rotation axis verticalverticalvertical
Number of rotorspcs333
Number of knives / rotorpcs444
Peripheral speed of knivesm/s363636
Maximum mulched material diametercm555
Frame typefoldingfoldingfolding
Maximum axle loadkg2 1502 1502 530
Maximum hitch loadkg1 0101 0101 240
Working angle of wings−15° to +45°−15° to +45°−15° to +45°
Recommended towing engine horsepowerhp120 - 140120 - 140150 - 200
Hitch typelug 40, 50 / K80lug 40, 50 / K80lug 40, 50 / K80
Total weight*kg3 1603 1603 770

*according to the machine equipment
