The robust frame of the mounted AN_PROFI high speed disc is a prerequisite for easy soil penetration and incorporation of large quantities of crop residue, together with a large blade diameter, 24″×0.24″. The mounted AN_PROFI speed disc is especially suitable for smaller farmers who want to till soil up to a depth of 6.5″.
2.5"-6.5" in
9' 10"-11' 6" ft
150-260 hp
A short, robust speed disc designed for cultivating soil up to a depth of 6.5″ and for incorporating large quantities of trash.
The main advantage of ATLAS AN_PROFI high speed disc is the disc section equipped with blades with a large diameter of 24″×0.24″. Individually mounted blades guarantee precise and stable guidance of blades in soil, achieving even cultivation of the soil profile. The blade gang can be equipped with notched or aggressive discs. Aggressive discs have a special shape that improves soil penetration and provides a better cutting and mixing effect.
The ATLAS AN_PROFI models offer outstanding underframe clearance that enables these robust speed discs to provide excellent mixing and incorporation of large quantities of organic matter, crop residue or cover crop.
The total weight of up to 7,385 lbs in combination with a robust frame allows to add additional weights of up to 440 lbs to the AN_PROFI models. The additional weights increases the down pressure on blade gangs and facilitates soil penetration that can be a problem especially when working during drought.
Setting the working depth of the implement is easy and comfortable using the tipping spacers located on the rear hydraulic cylinders that connect the frame of the tool with the frame of rear packers.
To ensure safe transport, the side blades are folded upwards. The blades can be folded mechanically, or hydraulically in the comfort of the cabin. The hydraulic design is especially suitable when the implement is transported on roads more frequently. The full working width of 9′ 10″ is achieved by unfolding the side discs into the working position.
Do not hesitate to contact us or find the dealer for your area.
Contact us Find a dealerA concise summary of the main working tools of the high speed disc
Easy connection to the three-point hitch of the tractor. Category II/III hitch
Comfortable hydraulic working depth setting from the tractor cabin.
Blade gang with notched or aggressive discs, with a diameter of 24″×0.24″ and auto-reset protection of each blade arm
Provides high underframe clearance in conditions with larger quantities of crop residue and allow to add additional weights.
Adds weight to the implement frame and facilitates disc penetration of soil.
Provide reverse consolidation and closure of the soil profile for even germination of leftover seeds and reduced evaporation of soil moisture.
The disc blades are placed in maintenance-free ball bearings with lifelong charge. The tightness of the bearing is ensured by a cartridge git seal. They are oversized, which ensures trouble-free operation.
FLEXI-BOX provides a maintenance-free mounting of arms to the frame. Each pin is fixed in a casing with special block. The design does not require any lubrication, and it also reduces micro-vibrations transmitted from the discs to the frame.
AUTO-RESET arms protection is provided by a horizontal spring, which provides ideal digging force of each disc blade. It is designed especially for heavier and dry soils.
“We purchased ATLAS AN_PROFI to replace an old disc harrow. We were convinced by the discs with a diameter of 24″, the spring protection, but above all, the hydraulically folding side discs and the hydraulic control of the depth. We do not need to get out of the tractor with this small speed disc“
Eta Selvia Patrick,
Francie
We know that everyone has different requirements for the optional implement equipment and its expected use. Therefore, you can specify your own ATLAS AN_PROFI speed disc to precisely match your needs.
The specially shaped disc blades offer a higher cutting and mixing effect. They also penetrate soil better in the dry season. The aggressive blades have a lot of cutting edges along the circumference for easy incorporation of a large quantity of trash. The sharp blades efficiently cut crop residue. Moreover, the profiled shape allows bringing out more soil. Available with a diameter of 24″ × 0.24″.
The disc gang is usually equipped with notched blades, with a diameter of 24″ × 0.24″.
U-RING is a steel packer suitable for all types of soil with quality crumbling and low stickiness. The individual rings are U-shaped. Packer diameter 19.5″. Weight: 882 lb/ft.
This packer consists of a cage and slatted packer with different diameters. The packer is suitable for cultivating medium and light types of soil in drier conditions. Packer diameter 18.5″ and 15″. Weight: 955 lb/ft.
V-RING is a heavy steel packer suitable for intense crumbling and reverse soil compaction. The packer is suitable for all types of soil. Packer diameter 25″. Weight: 1222 lb/ft (including scrapers).
The steel ring packer is made of massive steel rings for perfect compaction, suitable for all types of soil. The individual rings perfectly crumble clods. Packer diameter 21″. Weight: 1461 lb/ft. (including scrapers).
The cage packer is made of massive steel rods with a good crumbling effect, particularly when reaching higher working speed. Packer diameter 25″. A suitable design for light soils. Weight: 875 lb/ft.
PRIMARY TILLAGE
Quality and fast primary tillage is one of the most important operations in tillage. According to good agrotechnical practices, it should be carried out as soon as possible after the harvest. This will ensure the optimisation of soil moisture management, the rapid emergence of weeds and thus prevent the later weeding of land.
| ATLAS AN_PROFI | AN 10' PROFI | AN 11' PROFI | |
|---|---|---|---|
| Working width | ft | 9' 10" | 11' 6" |
| Transport width | ft | 9' 10" | 11' 6" |
| Transport length | ft | 10' 10" | 10' 10" |
| Transport height | ft | 5' 11" | 5' 11" |
| Number of disc blades | pcs | 24 | 28 |
| Working depth of disc blades* | in | 2.5" - 6.5" | 2.5" - 6.5" |
| Working angle of disc blades | ° | front 18 / rear 15 | front 18 / rear 15 |
| Disc blade diameter | in | 24" | 24" |
| Disc thickness | in | 0.24" | 0.24" |
| Type of disc blade protection | coil spring reset | coil spring reset | |
| Disc blade spacing | in | 9.8" | 9.8" |
| Distance between two ranks of disc blades | in | 43" | 43" |
| Underframe clearance | in | 27.5" | 27.5" |
| Horsepower requirement* | hp | 150 - 240 | 170 - 260 |
| Frame type | rigid | rigid | |
| Max. total weight** | lb | 6,172 | 7,385 |
*depends on soil conditions ** depends on the equipment
