The DURACUT TE trailed cutting roller is an implement for the efficient disposal and cutting of crop residues and cover crops. The V-shaped arrangement of the blades ensures high chopping effect. During operation, the entire weight of the frame and water in the rollers rests on the blades, a design that maximizes the crushing effect of the rollers, including shallow stubble cultivation. This field operation effectively starts the seed admixture growth process, for example after canola harvest.
24' 7" -41' ft
150-360 hp
Cutting roller for chopping and shallow stubble cultivation of trash in a single pass.
The DURACT TE is a highly interesting implement from an agronomic point of view. It offers an economical method for disposing of crop residues and mixing them with the topsoil. This field operation helps to promote the decomposition of trash and is a very effective way of combating certain pests such as the European corn borer and slugs.
The DURACT TE is a highly interesting implement from an agronomic point of view. It offers an economical method for disposing of crop residues and mixing them with the topsoil. This field operation helps to promote the decomposition of trash and is a very effective way of combating certain pests such as the European corn borer and slugs.
The DURACT TE is a highly interesting implement from an agronomic point of view. It offers an economical method for disposing of crop residues and mixing them with the topsoil. This field operation helps to promote the decomposition of trash and is a very effective way of combating certain pests such as the European corn borer and slugs.
The DURACUT TE can be equipped upon request with smooth, 914 mm diameter rollers, which can be used during the year for ground levelling (permanent pasture maintenance) or rolling the land after seeding to secure better seed-to-soil contact and reduce soil moisture evaporation. The rollers can be filled with water to increase the weight. Smooth and cutting rollers are easily interchangeable on the implement.
DURACUT TE cutting rollers are truly robust, equipped with 37″ diameter rollers. During rolling, the entire weight of the frame and water in the rollers rests on the blades. This solution maximizes the cutting effect of the rollers even on hard crop residues such as corn. In the case of the TE 40′, the roller weight per foot is 650 lbs. The cutting rollers can be filled with water to increase the chopping effect, where the weight is then up to 833 lbs per foot.
The DURACUT TE is designed with a V-shaped blade arrangement that allows for aggressive work and ideal results regardless of working conditions. This technical solution guarantees the so-called soil cutter effect (possibility of tilling even several inches of soil).
The DURACUT TE cutting roller comes in contact with a large amount of material during work. To guarantee maximum durability and minimum wear, the replaceable blades are made of HARDOX steel (the most recognized high-strength steel).
DURACUT TE has a middle frame and two side folding frames. Each roller is independently suspended to the frame. This technical solution ensures ideal terrain contouring, even when working on uneven ground. In addition, the individual rollers are positioned so that they overlap by only a few inches to ensure quality processing over the roller working width.
The DURACUT TE cutting roller uses the proven concept of folding and unfolding the implement into the shape of an “E” (middle frame and two side folding frames). This concept offers quick and easy folding of the roller from/to the transport position. In addition, the wide 700/40-22,5 tires ensure great tool stability during transport. The high ground clearance enables safe roller runs, for example along dirt roads.
Do not hesitate to contact us or find the dealer for your area.
Contact us Find a dealerThe main working tools of a trailed cutting roller in a concise and clear design.
Ensures easy and safe roller parking.
The robust frame contributes to the roller’s long service life and handles high working speeds.
Cutting rollers with a diameter of 37″. Standard or replaceable roller blades.
Each roller is independently suspended to the frame, a technical solution that offers perfect terrain contouring.
The replaceable blades are made of high-strength HARDOX steel can be easily replaced when necessitated by damage or wear.
The DURACUT TE has a middle frame and two side folding frames. Each roller is independently suspended from the support frame. This solution ensures excellent terrain contouring.
The DURACUT TE cutting roller comes in contact with a large quantity of material during work. To guarantee maximum durability of the blades and minimum wear, replaceable blades are made from HARDOX steel (most recognized high-strength steel).
Smooth rollers are feature of the implement to increase its utilisation throughout the year. Ideal for rolling land after seeding or maintaining permanent pasture.
The fixed blades are made of HARDOX high-strength steel (the most recognized high-strength steel). The blades are welded on.
The replaceable blades are made of HARDOX high-strength steel (the most recognized high-strength steel). The blades can be replaced in the case of damage or wear. The blades are bolted on.
You are one step closer to your new implement.
You can try all the implements in our configurator,
or read about it in the brochure.
CROP RESIDUE MANAGEMENT
Processing crop residue after harvest is important for several reasons. Crop residue is a source of organic matter therefore it is not desirable to simply leave it in the field without attention. Crop residue may be unevenly spread which aggravates tillage and the clumps facilitate the spread of diseases and breeding of pests.
| DURACUT | TE 24' | TE 40' | |
|---|---|---|---|
| Working width | ft | 24' 7" | 41' |
| Transport width | ft | 9' 10" | 9' 10" |
| Transport length | ft | 16' 9" | 27' 7" |
| Transport height | ft | 9' 10" | 11' 10" |
| Number of cylinders | pcs | 3 | 5 |
| Cylinder diameter – cutting | in | 37" | 37" |
| Cylinder diameter – smooth | in | 36" | 36" |
| Horsepower requirement* | hp | 150 - 250 | 250 - 360 |
| Hitch type | lug 40, 51, 55, 58, 62, 71, 73 | lug 40, 51, 55, 58, 62, 71, 73 | |
| Tire size | 700/40-22,5 | 700/40-22,5 | |
| Max. total weight - without water / with water (standard knives) | lb | 14,991 / 19,180 | 24,030 / 31,526 |
| Max. total weight - without water / with water (replaceable knives) | lb | 16,314 / 20,503 | 26,675 / 34,171 |
| Max. total weight - without water / with water (smooth rollers) | lb | 14,330 / 20,128 | 24,405 / 34,105 |
*depending on machine equipment
BEDNAR launches two new machines for processing catch crops and post-harvest residues: the SPEED CHOP SC_F cutting roller and the DURACUT TE heavy…
As usual, BEDNAR is launching new products as the current year draws to a close and the new 2025 business season begins.
9' 10" -19' 8" ft
90-200 hp
